Hot Water Gasoline Belt Drive HDC-4004-1H6A
HDC-4004-1H6A
The HDC Series is the most affordable and efficient skid on the market today. The best buy for a quick return on investment.
Pump: Belt drive triplex piston AR pump with ceramic plungers · Adjustable high pressure detergent injector
Engine: Performance-proven industrial gasoline engine with electric start - battery not included
Frame: Heavy-duty powder coated steel square tube skid frame · Stainless-steel coil wrap prevents rusting
Components: Stainless-steel wrap heat exchanger with 1/2-inch schedule 80 pipe coil · Polyethylene engine and burner fuel tanks · 12V Beckett burner - no need for generator - battery not included · No. 1 or No. 2 diesel or kerosene fired burner (Not approved for bio-fuel) · Large polyethylene float tank
Miscellaneous: Temperature rise 150°F/66°C above ambient, maximum outlet temperature is 200°F
Unit Includes: Quick connect nozzles 0°, 15°, 25° and 40° · 50-foot x 3/8-inch steel wire-braided high pressure hose · Adjustable pressure insulated dual lance · Insulated trigger gun with safety lock-off
Specifications
| PSI | 4000 |
| GPM | 4.0 |
| Displacement/Engine | GX630 Honda OHV |
| Pump | AR |
| Engine Fuel Tank Capacity | 10.0 gallon |
| Burner Fuel Tank Capacity | 10.0 gallon |
| Fuel Consumption | 2.45 GPH |
| BTU Per Hour | 343,000 |
| Drive Type | Belt Drive Pressure Washers |
| Mobility | Stationary Pressure Washers |
| Water Temperature | Hot Water Pressure Washers |
Weights & Dimensions
| Net Weight | 725.00 lbs. |
| Shipping Weight | 844.00 lbs. |
| Length | 50.00 in. |
| Width | 34.00 in. |
| Height | 46.00 in. |
Three-Way Ball Valve HX-0130
Allows pressure washer to be operated from garden hose/float tank or trailer supply tank by adjusting ball valve lever
Four-Point Lifting Capability HX-0147
Allows unit to be lifted by crane
Hour Meter HX-0156
Displays the number of hours unit has been in operation
Adjustable Temperature Control HX-0212
Operator is able to adjust outlet water temperature between 96°F-250°F
